Practice Calculations Set 1, Question 3 of 5

Calculate the transmitter peak power in watts, when the average power measured at UD1DCJ1 is 20dBm, PW=1.5 microseconds, PRF=1282Hz, and the loss from the klystron tube to UD1DC1J1 =34dB. UD1DC1J1 is the first place that the forward power can be measured.

Your answer ?    submit

solution

---
